Grade 304L Cold Drawn Stainless Steel Bar Dimension 19 - 350mm Flat Shape

Grade 304L Cold Drawn and H.R.A.P Stainless Steel Flat Bar Dimension 19-350mm

1, Production Details.

Manufacturing STANDARD:ASTM

SIZE STANDARD:JIS DIN ГОСТ

MATERIAL: 304L

OTHER MATERIALS AVAILABLE: 201,202,301,304,310,316,316L

CONDITION: Cold Drawn,Solution,Forged,Hot Rolled Annealing and Pickling,Polishing is available.

SIZE RANGE:

HOT ROLLED: Thickness 3~25mm, Width 20~320mm

FORGED:         Thickness 20-60mm,Width:20~350mm

COLD DRAWN:   Thickness 3-25mm,Width:19~180mm

LENGTH: Upwards 1000MM

TOLLERANCE OF LENGTH:

Length ≤4m··············0～+30mm
Length > 4m～6m··············0～+50mm
Length > 6m··················0～+70mm

Commercial Conditions:

Chemical Composition:

C :≤0.03% Si :≤1.00% Mn :≤2.00% P :≤0.20% S :≥ 0.03% Cr :18.00-20.00(%) Ni :8.00-10.00(%)

Mechanical Features

Tensile strength σb (MPa)≥520
Conditional yield strength σ0.2 (MPa)≥205
Elongationδ5 (%)≥40
Section shrinkage ψ (%)≥60
Hardness:≤187HBW;≤90HRB;≤200HV
Density (20℃,g/cm3):7.93
Melting point(℃):1398~1454
Specific heat capacity(0~100℃,KJ·kg-1K-1):0.50
Thermal conductivity(W·m-1·K-1):(100℃)16.3,(500℃)21.5
Linear expansion coefficient (10-6·K-1):(0~100℃)17.2,(0~500℃)18.4
Resistivity(20℃,10-6Ω·m):0.73
Longitudinal Modulus of Elasticity(20℃,KN/mm2):193

4, FAQ

Q: How long is your delivery time?

A: Generally it is within 20 working days after receiving deposit,and exactly it is according to quantity

Q: Do you provides samples? Is it free or extra?

A: Yes,we can provide the samples for free but we will not paythe cost of freight.

Q: What is your terms of payment?

A: Either by L/C OR by T/T.
