304 Stainless Steel Coil
Created with Pixso. Strong 304 Stainless Steel Coil 304DQ Grade Material Above 63% Elongation

Strong 304 Stainless Steel Coil 304DQ Grade Material Above 63% Elongation

Brand Name: Yongjin, Baosteel, Tisco
Model Number: 304DQ
MOQ: negotiation
Price: negotiation
Delivery Time: 4-8 weeks
Detail Information
Place of Origin:
China
Certification:
ISO,,PED,ASME,JIS
Grade:
304DQ
Quality:
Deep Drawing Quality
Elongation:
Above 63%
Application:
Home Appliance, Kitchen Utensiles, Water Sink,etc
Finish/Surface:
2B/BA/NO.4/HL
Thickness:
0.3-3.0mm
Width:
20-1250mm
Packaging Details:
standard export seaworth package
Supply Ability:
500mt per month
Highlight:

stainless steel 304 coil

,

stainless steel coil 304

Product Description

Deep drawing quality 304DQ cold rolled stainless steel coil & strip



Material: 304DQ cold rolled stainless steel coil & strip



Grade: 304DQ

Finish:  2B/2D/NO.4/HL/BA

Quality: Deep drawing, big elongation

Thickness: 0.3-3.0mm

Width:30-600mm,600-1250mm

Advantages: better deep drawing quality than common 304 grade, suitable for making deep drawing,                                bending and stretch forming.

Application: Home appliance (washing machine, dish washer,etc), kitchenware, water sink, other appliance                       need better deep drawing quality

Elongation: above 62%



GRADE RELATED GRADE
JIS GB ASTM EN
    304DQ  SUS304 06Cr19Ni10 S30400       1.4301



304DQ and 304Cu for deep drawing applications:

  C Si Mn P S N Ni Cr Cu
 304DQ  0.06 0.75 1.00~1.50 0.035 0.015 0.05 8.00~10.50 18.00~20.00 -
 304Cu  0.06 0.75 1.00~1.50 0.035 0.015 0.05 8.00~10.50 18.00~20.00 0.70~1.30



Mechanical properties:

GRADE YIELD STRENGTH TENSILE STRENGTH ELONGATION HARDNESS
%
  Mpa Mpa   HV
  304DQ 250~330 610~800 ≥62 150-175
  304CU 230~330 580~720 ≥62 140-170







Strong 304 Stainless Steel Coil 304DQ Grade Material Above 63% Elongation 0



Values we creat for you:

  • We are based in Ningbo,China,close to Ningbo seaport, multi-optional international sailing line available. You may share a low sea freight.
  • We enable to supply a wide variety of goods, from raw materials such as hot rolled and cold rolled coils/plates/sheets to downstream processing goods like stainless steel pipes,angle/flat/round bars,wire rods, as well as some auto exhaust pipes.
  • Different scale of quality,for certain kinds of goods, we may supply more than one option for our customer.
  • Diverse services for customers,except sales of physical goods, we may supply diverse services for our clients, such as slit big coils to smaller ones, “cut to length” for plates/sheets, OEM services etc.
  • Customized design, produce as per customer's request.
  • Provide 24hours phone services, you may find us at any time.
  • Quick response to your inquiry, email, problems and questions.
