1.4404 S30403 316 Stainless Steel Coil , 1000 - 1550mm Width Steel Sheet Coil

Name: 1.4404 S30403 316 Stainless Steel Coil , 1000 - 1550mm Width Steel Sheet Coil
Brand: Ningbo Juye Metal Technology co.,ltd
SKU: SUS316L 1.4404 S31603
Availability: InStock

Brand Name:	Baosteel Hongwang Jisco Yongjin
Model Number:	SUS316L 1.4404 S31603
MOQ:	negotiation
Price:	negotiation
Delivery Time:	around 30dd
Payment Terms:	by T/T in advance OR by irrevocable L/C at sight

Detail Information

Product Description

Detail Information

Place of Origin:

made in CHINA

Certification:

ISO9001 14001

Grade:

SUS316L 1.4404 S31603

Thickness:

0.3-3.0mm

Width:

1000-1550mm

Edge:

MIll Edge Or Slit Edge

Tolerance For Mill Edge:

+/-15mm

Country Of Origin:

Made In China

Lead Time:

30dd

Packaging Details:

Standard Export Packing

Supply Ability:

5000T/M

Highlight:

stainless steel roll

201 grade stainless steel

Product Description

1000mm~1550mm 316L cold rolled stainless steel coils SUS316L 1.4404 S30403

316L cold rolled stainless steel coils

Description of goods: 316L Cold rolled stainless steel coils
Serie: 300series
Grade: SUS316L 1.4404 S31603
Thickness:0.3-3.0mm
Finish 2B 2D BA NO.4 HL FH PVC/PE
Width:1000-1550mm
Standard: JIS ASTM AISI ASME EN
Coil ID: 508 or 610mm
Thickness tolerance:to be defined with customers
Surface treatment:Cold rolled,annealed, pickled
Coil weight; 8-10MT,9-11MT 4-6MT or as per your request
Paper Interleaved: Yes
Q'ty tolerance+/-10% on order quantity
Edge: MILL/SLIT

Main Commercial Conditions:

Payment terms	by T/T in advance or by irrevocable L/C at sight
Packaging	Seaworthy standard export package with pallet
Shipping date	about a month
Shipping terms	FOB CFR CIF etc.
Country of Origin	Made in China

CHEMICAL COMPOSITION of 316L

In accordance with different Normatives, there are different prescription on each chemical elements:

see here below the specific table:

STANDARD	GRADE	CHEMICAL COMPOSITION %
STANDARD	GRADE	C max	Si max	Mn max	P max	S max	N max	Ni	Cr	Mo
JIS	SUS316L	0.03	1.00	2.00	0.045	0.03	-	12.00~15.00	16.00~18.00	2.00~3.00
ASTM	S31603*	0.03	0.75	2.00	0.045	0.03	0.10	10.00~14.00	16.00~18.00	2.00~3.00
EN	1.4404	0.03	1.00	2.00	0.045	0.015	0.11	10.00~13.00	16.50~18.50	2.00~2.50
	1.4432	0.03	1.00	2.00	0.045	0.015	0.11	10.50~13.00	16.50~18.50	2.50~3.00
	1.4435	0.03	1.00	2.00	0.045	0.015	0.11	12.50~15.00	17.00~19.00	2.50~3.00

MECHANICAL PROPERTIES OF 316L

Tensile Strength (N/mm²) :480 MIN

Yield Strength (N/mm²):175 MIN

Elongation (%) :40 MIN

Density: 7.98g/cm3,

Hardness: HRB<90 HV<200 HBS<187

MAIN APPLICATIONS FOR GRADE 316L:

Instruments used in seawater, chemical dyes, paper, oxalic acid, fertilizer and other production equipment;
Heat exchanger for paper making equipment , dyeing machinery, film washing equipment, pipeline, Construction and building materials used in coastal areas.
Luxury watch chain and shell
Photography, food industry, coastal facilities, rope, CD rod, bolt, nut etc
