Thermal Fatigue Resistant 430 Series Stainless Steel Roll SUS430 1.4016 S43000 Grade

Name: Thermal Fatigue Resistant 430 Series Stainless Steel Roll SUS430 1.4016 S43000 Grade
Brand: Ningbo Juye Metal Technology co.,ltd
SKU: SUS430 1.4016 S43000
Availability: InStock

Brand Name:	Baosteel Jisco Yongjin
Model Number:	SUS430 1.4016 S43000
MOQ:	negotiation
Price:	negotiation
Delivery Time:	around 30dd
Payment Terms:	by T/T in advance OR by irrevocable L/C at sight

Detail Information

Product Description

Detail Information

Place of Origin:

made in CHINA

Certification:

ISO9001 14001

Grade:

SUS430 1.4016 S43000

Thickness:

0.3-3.0mm

Width:

1000-1550mm

Tolerance For Mill Edge:

+/-15mm

Country Of Origin:

Made In China

Lead Time:

30dd

Shipping Terms:

EXW FOB CFR CIF

Finish:

NO.1、1D、2D、2B、N0.4、HL、BA、Mirror

Packaging Details:

Standard Export Packing

Supply Ability:

5000T/M

Highlight:

430 grade stainless steel

stainless steel cold rolled coils

Product Description

1000mm~1550mm 430 cold rolled stainless steel coils SUS430 1.4016 S43000

430 cold rolled stainless steel coils

Quick Detail

Description of goods:430 Cold rolled stainless steel coils
Grade: SUS430 1.4016 S43000
Thickness:0.3-3.0mm
Finish: NO.1,1D,2D,2B,N0.4,HL,BA,Mirror
Width:1000-1550mm
Standard: JIS ASTM AISI ASME EN
Coil ID: 508 or 610mm
Thickness tolerance:to be defined with customers
Surface treatment:Cold rolled,annealed, pickled
Coil weight; 8-10MT,9-11MT 4-6MT or as per your request
Paper Interleaved: Yes
Q'ty tolerance+/-10% on order quantity
Edge: MILL/SLIT

CHEMICAL COMPOSITION AND FOR 430

STANDARD	GRADE	CHEMICAL COMPOSITION(%)
STANDARD	GRADE	C max	Si max	Mn max	P max	S max	Ni	Cr
JIS	SUS430*	0.12	0.75	1.00	0.040	0.030		16.00~18.00
GB	1Cr17	0.12	1.0	1.00	0.040	0.030	0.75	16.00~18.00
ASTM	S43000*	0.12	1.0	1.00	0.040	0.030	0.75	16.00~18.00
EN	1.4016	0.08	1.0	1.00	0.040	0.015		16.00~18.00

MECHANICAL PROPERTIES

Material	Yield Strength	Tensile Strength	Elongation	Hardness
Material	(N/mm2)	(N/mm2)	(%)	HRB	HV
430	≥205	≥420	≥22	≤80	≤200

MAIN APPLICATIONS FOR GRADE 430:

430 stainless steel is common-used steel, has good corrosion resistance, has better thermal conductivity than austenitic stainless steel, it’s thermal expansion coefficient is smaller than the austenitic stainless steel, is resistant to thermal fatigue, due to adding stabilized element titanium, has good mechanical properties on welding position.

430 stainless steel is used in building and decoration, household appliances, fuel burner parts,white appliance parts etc.
