5mm - 38mm Dia Stainless Steel Wire Rod Excellent Corrosion Resistance

Name: 5mm - 38mm Dia Stainless Steel Wire Rod Excellent Corrosion Resistance
Brand: Ningbo Juye Metal Technology co.,ltd
SKU: ER308 ER308L ER308LSi
Availability: InStock

Brand Name:	JUYE
Model Number:	ER308 ER308L ER308LSi
MOQ:	negotiation
Price:	negotiation
Delivery Time:	Within 45 dd
Payment Terms:	100% payment by irrevocable L/C at sight

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang,China

Certification:

ISO

Description:

Stainless Steel Wire Rod

Standard:

JIS AWS

Diameter:

5m~38mm

Length:

As Per Customer's Requirement

Grade:

ER308 ER308L ER308LSi

Shipping Terms:

CFR CIF FOB Etc

Country Of Origin:

China

Packaging Details:

Standard export sea-worthy package.

Supply Ability:

500T

Highlight:

steel wire rod coils

steel wire coil

Product Description

ER308 ER308L ER308LSi stainless steel wire rod diameter 5mm~38mm for welding

Material

Grade	Standards
Grade	GB/T T4241-2006	JIS Z3221/JIS Z3321	AWS A5.4 AWS A5.9
ER308	H08Cr21Ni10	ES308	E308H
ER308L	H03Cr21Ni10	ES308L	E308L
ER308LSi	H03Cr21Ni10Si	SUSY308	ER308R

Quick Detail

Size: 5mm,5.5mm,6mm,5mm,7mm,7.5mm,8mm,8.5mm,9mm,9.5mm,10mm,11mm,11.5mm,12mm,13mm,15mm,16mm,17mm,18mm,19mm,20mm,21mm,22mm,23mm,24mm,25mm,26mm,28mm,30mm,32mm,34mm,38mm

Coil weight:from 500kg to 2500kg

Standard:JIS Z3221,AWS A5.4

Materials:ER308 ER308L ER308LSi

Grade :A B C according to the attached tollerance table

Application:for welding

Tolerance accordiing to the attached the table.

Tolerance Table

Diameter (mm)	Tolerance(mm)			Ovality(mm)
Diameter (mm)	Grade A	Grade B	Grade C	Grade A	Grade B	Grade C
≥5.0~10	±0.30	±0.25	±0.15	≤0.50	≤040	≤0.24
>10~15	±0.40	±0.30	±0.20	≤0.60	≤0.48	≤0.32
>15~25	±0.50	±0.35	±0.25	≤0.70	≤0.56	≤0.40
>25~38	±0.60	±0.40	±0.30	≤0.96	≤0.64	≤0.48

Chemical Composition

Grade	Chemical Composition(%)
	C	Si	Mn	P	S	Ni	Cr	Cu	Mo	N



ER308	≤0.05	≤0.25	1.50-2.25	≤0.025	≤0.015	9.50～11.00	19.50～22.00	≤0.30	≤0.50	≤0.06
ER308L	≤0.025	≤0.25	1.50-2.25	≤0.025	≤0.015	9.50～10.50	19.50～22.00	≤0.30	≤0.50	≤0.06
ER308LSI	≤0.025	0.40-0.65	1.50-2.50	≤0.025	≤0.015	9.50～10.50	19.50～22.00	≤0.50	≤0.75	≤0.10
