Welding Spring Screw 38mm 304H Stainless Steel Wire Rod

Brand Name:	JUYE
Model Number:	304/316
MOQ:	Negotiable
Price:	To be discussed
Delivery Time:	10-20 days
Payment Terms:	by T/T in advance or by irrevocable L/C at sight

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO IQNet

Packaging Details:

Standard export packing or according to customer 's requirement

Supply Ability:

1000T a month

Highlight:

38mm Stainless Steel Wire Rod

304H Stainless Steel Wire Rod

Product Description

Detailed Product Description

Description:	Stainless Steel Rod	Grade:	Grade A
Diameter:	5mm~38mm	Application:	Metal Line And Cold Heading
Shipping Terms:	CIF FOB CFR	Coil Weight:	500kg~2500kg
Country Of Origin:	Made In China	Standard:	JIS G4303 JIS G4311 ASTM A959 EN10088-3

304H stainless steel wire rods for hardware wire diameter Φ5mm~Φ38mm

Material

Grade	Standards
Grade	GB/T 20878-2007	JIS G4303:2005	ASTM A959-09	EN 10088-3:2005
304H	07Cr19Ni10	SUH304H	S30409	1.4948

Main Specification:

Description:Stainless steel rod

Grade:304H

Diameter: 5mm,5.5mm,6mm,5mm,7mm,7.5mm,8mm,8.5mm,9mm,9.5mm,10mm,11mm,11.5mm,12mm,13mm,15mm,16mm,17mm,18mm,19mm,20mm,21mm,22mm,23mm,24mm,25mm,26mm,28mm,30mm,32mm,34mm,38mm

Coil weight: 500kg~2500kg

Dimensional Tolerance: Grade A,Grade B,Grade C

Length:Cut to customer needs

Dimensional Tolerances for stainless steel wire rod

Diameter (mm)	Tolerance(mm)
Diameter (mm)	Grade A	Grade B	Grade C
≥5.0~10	±0.30	±0.25	±0.15
>10~15	±0.40	±0.30	±0.20
>15~25	±0.50	±0.35	±0.25
>25~38	±0.60	±0.40	±0.30

OvalityTolerances for stainless steel wire rod

Diameter (mm)	Ovality(mm)
Diameter (mm)	Grade A	Grade B	Grade C
≥5.0~10	≤0.50	≤040	≤0.24
>10~15	≤0.60	≤0.48	≤0.32
>15~25	≤0.70	≤0.56	≤0.40
>25~38	≤0.96	≤0.64	≤0.48

Chemical Composition:

Grade:304H

C:0.04-0.10%

Si:≤1.0%

Mn:≤2.0%

P:≤0.045%

S:≤0.030%

Cr:18%-20%

Ni:8%~11%

Cu:0.50%

N:≤0.15%

Features and Application

Due to high strength, elastic stability, good fatigue resistance, good corrosion resistance in outdoor harsh environment, so it's widely used for making spring, steel strand and cable etc.
